Sizes: 12mm - 60mm
The SS thimbles are heavy duty and usable for wire ropes but are specially designed for DYNEEMA® ropes.
We can supply the thimbles with GUNNEBO® master-links or other components on request.
The spare gussets are available if needed for special rigging.
| Part Number |
A mm |
B mm |
C mm |
D mm |
E mm |
Weight kg |
|---|---|---|---|---|---|---|
| 800362 | 12 | 84 | 21 | 2.2 | 7 | 0.33 |
| 800365 | 15 | 91 | 27 | 5 | 9 | 0.39 |
| – | 19 | 113 | 31 | 5 | 11 | 0.79 |
| – | 24 | 136 | 46 | 5 | 15 | 1.04 |
| – | 27 | 142 | 45 | 5 | 15 | 1.29 |
| 800368 | 31 | 163 | 48 | 7 | 19 | 1.84 |
| – | 39 | 179 | 60 | 5.5 | 20 | 1.68 |
| – | 48 | 220 | 74 | 5.5 | 32 | 2.71 |
| – | 60 | 260 | 81 | 8.5 | 38 | 5.75 |
