Description
| Part Number |
Diameter mm |
Inside Length (Pitch) mm |
Inside Width mm |
Outside Width mm |
Outside Length mm |
Safe Working Load 5:1 ton |
Weight kg/m |
|---|---|---|---|---|---|---|---|
| A | B | C | D | E | |||
| CHG806SP | 6.0 | 20.8 | 6.3 | 22.3 | 32.8 | 1.1 | 0.852 |
| CHG807.1SP | 7.1 | 23.8 | 7.1 | 25.9 | 38 | 1.6 | 1.14 |
| CHG808SP | 8.0 | 23.8 | 8 | 27 | 39.8 | 2 | 1.4 |
| CHG810SP | 10.0 | 29.8 | 9.7 | 33.8 | 49.8 | 3.2 | 2.08 |
| CHG813SP | 13.0 | 38.0 | 12.7 | 43 | 64 | 5.3 | 3.49 |
| CHG820SP | 20.0 | 59.2 | 20 | 67.5 | 99.2 | 12.5 | 8.78 |
